RADtec E-Series Heater E24R

The RADtec E-series 62” Infrared Radiant Heater - E24R is built around a premium Epoxy Powder Coated 6063 Aircraft Aluminum Housing that is painted all-black to maximize aesthetics and let it blend into any concept of your home. The remote is fully functional and very handy while operating the unit. Its remote control features 4 variable Heat Settings (2/4/8 hour time functions), On/Off capability, Fan mode options and much more.

This product has a powerful 2400-Watt infrared heater with a carbon fiber element that requires to be hardwired anywhere in your office or home. The robust heater covers up to 65 sq. ft and emits zero light while operating. Backed with a 3-year warranty, this heater has a strong operational lifespan of 20,000 - 30,000 hours! Get value for your money and heat up your home with the RADtec E-series 62" Infrared Radiant Heater.

DOWNLOAD PRODUCT MANUAL HERE

CAD Details:

Ceiling Side and End Elevation

Dimensions and Electrical Requirements

Wall Mounted Side Elevation

WHAT'S IN THE BOX:

Infrared Electric Heater - 1 pc.
Mounting Brackets - 1 set
Handheld Remote - 1 pc.
User's Manual - 1 pc.

Warranty	Three (3) year
Remote Control	Included
Mounting Kit	Included
Color	All Black
No Glow	Yes

Wattage	2400W
Amps	10A
Voltage	220-240V
Plug Type	Pigtailed (Hard Wired)
Water Rating	IPX4

Dimensions	62.5 x 7 x 2.5 in.
Weight	24 lbs.
Element	Carbon Fiber
Heat Coverage Area	65 ft²
Shipping Weight	27 lbs.
Shipping Dimensions	67 x 10 x 6

RECOMMENDATIONS:

The recommended installation height of the E Models is 84”- 108” from the floor. Under no circumstances is the heater to be installed at less than 71” from the floor. In all cases, it should be installed at a height where it cannot be touched in operation. The heated zones detailed are based on the recommended mounting heights.

In exposed areas with air movement/wind, the far-infrared spread may reduce by 1/3. In such areas, or when used in low air temperatures, we would recommend considering a heater from our medium wave Genesis Series or proportionally increasing the number of E Model heaters and mounting at the lowest height.
