Note: Processing time can take between 1-3 business days. Delivery between 3-5 business days.



The RICH SOLAR 100 Watt 12 Volt Polycrystalline Solar Panel is a key component in establishing an off-grid solar energy system. Weighing in at only 17.5lbs, this panel contains 36 efficient polycrystalline solar cells protected by a thin layer of tempered glass. Use this panel alone or add additional panels to create a custom solar energy system.

• 12V off-grid solar panel
• 0~+5W guaranteed positive power output
• IP 65 or IP 67 Rated
• Built with strong tempered glass and aluminum frame
• Certified to withstand challenging environmental conditions
• Excellent low light performance on cloudy days, mornings, and evenings

Installation

• Easy installation and handling for various applications
• Pre-drilled holes compatible with ground mounts, Z-brackets, pole mounts, and tilt mounts
• Compatible with on-grid and off-grid inverters

Warranty

• 25 years 80% output power.
• 5 years of materials and workmanship.

Built-in Components

• RICH SOLAR 100 Watt Monocrystalline Solar Panel
• Panel Leads (Pair): 12AWG, 3FT each
• IP65 Rated waterproof junction box
• IP67 Rated waterproof solar connectors

Specifications

Maximum Power(Pmax)	100W
Maximum Power Voltage(VMP)	18.2V
Maximum Power Current(Imp)	5.49A
Open Circuit Voltage(Voc)	22.1V
Short Circuit Current(Isc)	5.93A
Maximum System Voltage(Vmax)	600V DC
Weight	15.5 lbs
Dimensions	39.0 x 21.3 x 1.2 inches

Download the User Manual Here
